PN: 25 5012 A

2 Knuckles including Grade 8 and Nord-Lock Spindle Mounting Hardware

• Made with High Strength T1 Steel, will not deform or crack like typical mild steel. These are the strongest knuckles on the market, hands down.
• Larger 7/16 Spindle Mounting Bolt Holes
• Lifetime Warranty
• Factory Camber Has Been Removed
• Accepts The Factory Boot
• Double Shear Steering Arms Available With A 1" Or 3/4" Thru Hole.
• 100% Canadian Made right here in Central Alberta, by a Local Small Business Freestyle Projects

*Because of all the different styles and sizes of Steering Heim Joints the Steering Arms Will Be Shipped Loose. If Specified At The Time Of Ordering Everything Can Be Welded on for an additional $250*

Includes:

• 2 Plate Steel Knuckles
• 2 Upper Steer Lugs
• 2 Lower Steer Lugs
• 4 Steer Lug Gussets
• 24 7/16" Grade 8 Bolts
• 24 Nordlock Washers

**Disclaimer**

When drilling your stock spindle, use a 29/64" drill bit, be sure to use a quality drill press or milling machine to make sure the holes are drilled square to the old holes. If drilled by hand it is common for the spindle holes to not line up perfectly with the knuckle

2.5 Ton Inner Hub Seal Install Tool

Will work with Front and Rear Axles, uses the factory Spindle nuts, to press the seal onto the spindle.

You will require a Spindle Nut Socket to properly utilize this tool, we carry them in OEM and DIY, please see the video below for further instructions.

PN: WCR 7150

**Back in stock May 9**

PN: 25 2201

EMF's Rockwell 2.5 Ton Pinion Brake Kit contains everything you need to set up your Rockwell Pinion Braking System. Much higher quality than most brake kits on the market, will not fade, distort or crack under hard use. Rotor mounts on the back side of the 2.5 Ton flange, so it can be used on the driveline side of the axle or the empty yoke side.

Standard Kit Includes: PN 25 2201

• 10" Non-Vented Rotor, will not plug with mud burning out brake pads
• Wilwood Caliper
• Poly Matrix Wilwood Brake Pads
• 1/4" Pinion Brake Mount Bracket

Pinion Brake Kit with Extras Includes: PN 25 2201 E

• 10" Non-Vented Rotor, will not plug with mud burning out brake pads

• 2x Wilwood Calipers
• 2x Poly Matrix Wilwood Brake Pads
• 2x 1/4" Pinion Brake Mount Bracket
• 2x Pinion Brake, 2.5 Ton Bolt Kit

Bolts Required (Option to purchase bolt kit) PN: 25 2251 K:

• (3x) 1/2"x1-3/4" NC Bolt Gr 8
• (4x) 1/2"x2-1/4" NC Gr 8 Bolt
• (2x) 3/8"x1-1/2" NC Bolt Gr 8
• (8x) 1/2" Flat Washer

• (4x) 3/8" Flat Washer
• (2x) 3/8" NC Stover Nut
• (3x) 1/2" Lock Washer
• (4x) 1/2" NC Stover Nut

10" diameter made from solid billet steel will not warp like plasma cut rotors, or heat check and fail like cast rotors. No vent holes prevent mud and sand from building up between the pad and rotor causing premature wear, the thick steel rotor is very resilient to damage if it comes in contact with an obstacle. Also because they are 3/4” thick solid steel, this means it is possible to machine them multiple times and bring them right back to new!

These are premium brake kits with top of the line parts, designed specifically for those who desire the best and safest brake Kit on the market!

The Tierod Taper Kit allows you to remove the factory taper from the steer arm of the knuckle allowing you to run a 3/4" bolt and Heim Joint setup.
For 1" bolts you can simply drill out the factory arm. Be aware that this can significantly weaken the arm and could result in failure and therefore not recommended.

Sold in Pairs

2.5 Ton High Steer Arms, made from T1 steel, with a built in double shear tube to help tie into the stock steer arm, sharing the load of the Steering Ram. Heim Joints can be run above or below the arm by shortening the tube.

High Steer arms are sold with the intention to run the Heim Joint above the Steer Arm, if you wish to run the Heim below the Steering Arm, the tube will need to be modified once received or we can modify for you, if Heim Joint width is specified before ordering.

These arms also work great in conjunction with our high steer ram mount

Bolts required:

• 8x 9/16"x2" Grade 8 Bolts
• 8x 9/16" Grade 8 Lock Washers

Kit Includes:

• 1x LH Arm
• 1x RH Arm
• 2 Taper Elimination Cones for the stock tie rod hole

Eliminate factory Steering arm on the 2.5 Ton Axles, along with the pesky Cone Washers when using full Hydraulic Steering. This is made from a high strength grade of T1 Steel, new King Pin Caps are a significant upgrade for the lower factory King Pin Caps that can bend, distort or crack under hard use.

They are a necessary update for your lower caps if you are jumping or competing with you're 2.5 Ton Rockwell Axles, our upgraded King Pin caps come with a lifetime warranty against bending or breaking

Reman Cap:

Less expensive reman plates are a great option for rigs not seeing excessive use, or can be used on the upper king pin as there's significantly less load on the upper king pin.

Made from High Strength Laser Cut T1 Steel. Will not flex or bend like normal mild steel, weld washers are not required, these are built from the highest grade steel on the market.

If you want to do your brackets once and not have to worry about replacement or repair in the future this is the Kit you want!

Width can be adjusted for different Heims. Contact for Custom Size Bolt Holes

This is for one Axle, comes with:

• Top Plate (Front, Front Flipped, Or Rear)
• Side Plates And Spacer Plate
• 2 Short Lower Link Mounts
• 2 Long Lower Link Mounts
• 4 Flat Mount Link Tabs

Bolts Required (Option to purchase bolt kit):

• (6x) 1/2"x2" NC Bolt Gr 8
• (8x) 3/8"x1.75" NC Bolt Gr 8
• (4x) 3/8"x1" NC Bolt Gr 8
• (6x) 1/2" Lock Washer
• (12x) 3/8" Lock Washer

 When installing the 2.5 Ton Top Hat, leave the diamond shaped side plate and rectangle top in place. Due to difference in manufacturing, the top may have to ground down a bit slightly in the area shown, in the spacer plate image.

Made from High Strength Laser Cut T1 Steel. Will not flex or bend like normal mild steel, weld washers are not required, these are built from the highest grade steel on the market, 12" of link separation is good for 50"+ tires, Width can be adjusted for different Heim spacing.  Contact for Custom Size Bolt Holes,

This is for one Axle, comes with:

• 4 Tower Plates
• 2 Support Plates
• 2 Short Lower Link Mounts
• 2 Long Lower Link Mounts

Our version of the 2.5 Ton high clearance Diff Pan, of course it's made from the same high strength T-1 steel we build everything from.

Each pan is fully welded on both sides, meaning it will be the strongest part of your Rockwell housing! The added clearance will help keep you from dragging your diff pan on obstacles. We've also designed the pans to have the least amount of flat edges that way they're a lot less for you axle to get hung up on!

Built from 3/8" thick Steel, fully Welded inside and out, drain holes are placed so mud and grass can be washed out easily, Lower Grease Nipple Guard, an addition of an Upper Protective Plate built from 1/4" Steel that adapts to the Lower Guard helping to keep the entire Boot protected from sticks and debris.

Sold in pairs, with all new mounting hardware

Lower Guards are sold separately if you're unable to run the Upper Half. Contact for Pricing.

Full Kit Includes:

• 2 Lower Boot Guards
• 2 Upper Boot Guards
• Boot Guard Mounting Bolt Kit

Lower Kit Includes:

• 2 Lower Boot Guards
• Boot Guard Mounting Bolt Kit

**These boot guards may require modifications if used with Axle Truss's**

2.5 Ton Center Chunk can be flipped to center the Pinion on a Steering Axle, this Jig WCR0315A, allows you to quickly and easily redrill the holes in your chunk so that it can be run in either orientation.

2.5 Ton Center Chunk can be flipped to center the Pinion on a Steering Axle, this Jig WCR0314A, allows you to quickly and easily redrill the holes in your axle so that it can be run in either orientation.

Breathing line kit for your Rockwell Axles, will fit most Axles.

Kit includes enough line and fittings for one Axle:

• 25 feet of 1/4" Air Line
• 1/8" NPT Compression Fitting
• Nylon tubing is flexible and durable but will not collapse like rubber hose

Replace the weak grade 5 studs, each kit features ultra strong grade 8 bolts and Nord-Lock washers for an entire axle

Includes:

• 24 Grade 8 Bolts
• 24 Two Piece Nordlock Washers

Steering ram mounts for Dual, Double Ended or Single Ended Steering Rams

2.5 Ton Spool, this is a drop in 16 Spline Spool made from Billet Steel, this spool only replaces your 2.5 Ton Spider Gears, and not the entire carrier.

Please see the tutorial for installation guidelines.

SPOOL TUTORIAL

Genuine Yukon Grizzly Locker

**CONTACT FOR AVAILABILITY**

Replace the incredibly weak 2.5 ton stock Tie rod with HD upgraded version, this is very important if you plan to mount a steer ram to the tie rod

Stock Replacement Kit Includes:

• 4.5'x 1.5" .250 Wall Tubing, threaded
• 2x 1-1/8" Jam Nuts, 1 Left Hand and 1 Right Hand. Will work on stock TieRods
• Tie rod ends are not included with this kit

XM Kit Includes:

• 4.5'x 1.75" .375 Wall DOM Tubing
• 2x 1.25" XM Heim Joints (LH +RH) Jam nuts, weld bungs
• 2x Taper Elimination Cones (available in 3/4" or 1") Meritor/5 Ton
• Tie rod is welded and ready to assemble

 The 2.5 Ton Kit comes in a 1" or 7/8" Kit, the 1" kit you will have to drill out your steering knuckle, the 7/8" kit comes with a bushing to take it down to a 3/4" bolt with out having to drill out your knuckle.

**For custom Tierods please contact us**

Gen 2.0

Help reduce the load on your lower King Pins with this Kit, unlike other kits on the market these provides support, not only in the vertical axis, but in all axis. This greatly improves the strength of your 2.5 Ton Axles when used for jumping or competition.

The added strength of a King Pin support, without sacrificing ground clearance! Built for maximum clearance, they also provide a substantial amount of support to your lower King Pins, they also pull double duty as Boot Guard!

This Kit comes welded, some fitment and additional welding is required.

Gen 1.0

Our proven First Gen King Pin supports have been pushed to the absolute max and have proven to keep your King Pins where they belong!

Basic

The Basic Kit that will keep you from breaking your bank and your King Pins all at the same time!

**THESE KITS ARE SOLD PER AXLE**

Available in Welded and Non-Welded DIY configuration

Welded Sockets are laser cut end caps, welded to a piece of pipe, socket drive is 1/2"

DIY Kits Include: PN: 25 7206 A

• End Cap with 1/2" Drive
• Socket Cut out

DIY Kit requires 4.5" of 4.5" OD Tube

Welded Kit Includes: PN: 25 7207 A

• Fully Welded Socket with End camp and Socket cut out

Replacement caliper for Pinion Brake Kit

will work with all 3/4" wide rotors

Replacement pads for Pinion Brake Kits, are Wilwoods premium Poly Matrix Brake Pads, specifically designed for high heat, high wear applications such as Pinion Brakes

Kit includes:

• 24x Anti Vibration Washers
• 24x 3/8" x 1" Grade 8 Bolts

When flipping the hubs on a steer 2.5 Ton Axle to run a narrow track width, you will need to remove the factory Spindle Studs, then replace them with this kit that allows the backside of the Wheel Studs to clear the Spindle bolt heads. Keep in mind some grinding on the backside of the Wheel Studs will be required. This kit will make sure the amount of material needed to be removed will be an absolute minimum.

Features Grooved Non-Slip Casting and machined for use with four (4) clamps.

• (1x) Budget Double Ended Ram 10” Stroke x 2.5” Bore 1.5” Rod

Optional Kits

With Tie Rod Kit:

• (1x) Budget Double Ended Ram 10” Stroke x 2.5” Bore 1.5” Rod
• (1x) SC16 - Clevis Kit
• Tie Rod with Rod Ends


  Turns Lock to Lock 2.5x10 with the following Orbitals:

• 200cc 2.6 Turns
• 250cc 2.1 Turns

Turns Lock to Lock 2.5x8 with the folowing Orbitals:

• 200cc 2.1 Turns
• 250cc 1.6 Turns
