32 Spline

End Yoke - Splined Bore

FORGED 1410 series, Strap Kit Style, Ø1.401x 32 spline, Ø2.125 hub diameter.

This Forged 1410 series yoke is designed to fit the 32 spline front and rear output shafts of New Process 205, 203, and Atlas transfer cases. The yoke has the required chamfer at the base of the hub to clear the bearing cage on Atlas transfer cases.

End Yoke - Splined Bore

FORGED 1410 series,  Strap Kit Style,Ø1.326x30 spline, Ø1.750 hub diameter.
GM NP203 and NP205 30 spline front outputs.

We designed this 1410 series  Strap Kit Style, yoke to fit the 30 spline front output shaft common on GM NP203 and NP205 transfer cases in the 70s and 80s

10 Spline

End Yoke - Splined Bore

FORGED 1410 series,  Strap Kit Style, Ø1.250x 10 spline, Ø1.750 hub diameter.
GM NP205 10 spline front outputs.

All yokes come with bolt & strap kits.

If you require U-bolts instead of strap kits pls contact us before purchasing.

32 Spline

This 1410 / 1480 series companion flange is designed to fit the 32 spline front and rear output shafts of New Process 205, 203, and Atlas transfer cases. The flange has the required chamfer at the base of the hub to clear the bearing cage on Atlas transfer cases.

30 Spline 14 Bolt Companion Flange

This is a factory replacement ball bearing for the output of all NP205.

These are a genuine replacement seal for the output yokes on all NP205.

Make sure to measure the diametere of the seal surface on your yoke before ordering.

These billet bearing retainers are perfect to urgrade those broken down and cracked cast bearing retainers.

They are made from 6061-T6 Aluminum and are fully CNC machined.
